Sand recycling machine is a device for extracting solid sand from slurry material, also called fine sand extractor. The machine is mainly used for the recovery and dewatering fine sand in the waste water discharged by the the wheel sand washing machine or the spiral sand washing machine. On the one hand, the fine sand extracted to obtain a better grade sand output mixed coarse and fine, on the other hand, it can solve the serious accumulation of sedimentation tank after washing sand.

Working principle

The overflow mouth before washing sand machine, aggregate recycling machines into the mouth, recycling machine aggregate the bottom and the slurry pump connection, slurry pump, pumping slurry into the hydrocyclone and rated filling pressure, through high-speed centrifugal force cyclone separating the sand in the pulp, at the same time after the sand concentration up to 60-70% through heavy spit into linear vibrating sieve dehydration screen surface, under the action of vibration sieve machine, the moisture in the sand removal. Fine sand in the sieve machine screen surface do linear jump movement, discharge from the outlet conveyor belt, so as to achieve the purpose of fine sand in the pulp recovery, dehydration, dry discharge.

Tech specifications

Structure

Spare parts

Q Payment terms

A T/T. earnest money (30% of total amount) to be paid in advance, the rest amount to be paid after Inspection and before goods leaves factory.

Q

What can I get the price?

A

We usually quote within 24 hours after we get your inquiry. If you are very urgent to get the price, please tell us in your email so that we will regard you inquiry priority.

Q

What is your term of delivery?

A

We accept EXW, FOB Shanghai or FOB Qingdao. You can choosethe one which is the most convenient or cost effective for you.

Q

What about the lead time for the mass production?

A

Honestly, it depends on the order quantity and the season you place the order.
